Mini Dual-Tech Presence Sensor (2 Switch)

No.Mini-DTP-S2
P/N:
The CTL-SEN-Mini/3111.F22 is an advanced Dual-Tech Presence Sensor designed for high-precision occupancy detection.
$65.10 $32.60
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • Color:
    White
    Black
    Please select the information you wantX
Quantity:
-
+
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
1/1
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Mini Dual-Tech Presence Sensor (2 Switch),CREATROL SENSOR,Mini Dual-Tech Presence Sensor (2 Switch)
  • Description
  • Resources

Overview

The CTL-SEN-Mini/3111.F22 is an advanced Dual-Tech Presence Sensor designed for high-precision occupancy detection. The sensor utilizes a Pyroelectric Infrared (PIR) sensor to detect biological movement characteristics, while simultaneously using 24 GHz FMCW radar to detect active motion, micro-motion, and stationary presence. By performing dual-signal cross-verification, the device triggers only when both technologies consistently confirm human activity, thereby minimizing false alarms to the maximum extent.

Features

  • Dual-technology fusion of PIR (Passive Infrared) and 24GHz FMCW radar minimizes false triggers.
  • Accurately identifies motion, micro-motion, and Presence.
  • Sensitivity and detection distance can be adjusted independently.
  • Integrated high-precision sensor for accurate indoor illuminance monitoring.
  • Features 2 relay output
  • Adjustable lighting threshold.
  • Supports parameter configuration and status readout via IR remote control.
  • Indicator LED brightness automatically adjusts to ambient light levels.
  • Powered by a proprietary module with advanced signal processing algorithms.

Specifications

Output Type Mains Output
BOX Input Voltage AC 100 to 240 V
BOX Output Voltage DC 12 V (0.25 A MAX)
Sensor Input Voltage DC 12 V
Power Consumption 0.5 W (Max)
Relay Output Normally Open Mode
Normally Closed Mode
Relay Load AC 100 to 240 V, ≤ 5 A
Indicator Light LED
Detection Mode PIR + 24GHz FMCW Radar
Operating Frequency 24.00 to 24.25 GHz
Transmit Power ≤ 10 dBm
Installation Method Recessed Ceiling Mount
Mounting Height 2.0 to 3.2 m
Detection Angle 360°
Detection Coverage Installation at 3.0 m Height:
① Motion & Micro-motion: Detection diameter at least 8.0 m
② Stationary Presence: Detection diameter at least 6.0 m
Detection Range 1.5 to 8.0 m (sensor to target)
Sensitivity 0 to 100%
Illuminance Monitoring 0 to 32,000 Lux (Accuracy ±4%)
Delay Time 1 to 3,600 seconds
Product Size Φ43 mm × 25 mm
Cutout Size Φ35 mm
Product Weight 16.5 g
BOX Size 121 mm × 35 mm × 26 mm
BOX Weight 88 g
Cable Assembly UL2468 22AWG
Cable Length: 200 mm
Operating Environment Indoor -20 to 45°C
Humidity < 95% RH (Non-condensing)
Storage Temperature -40 to 85°C
Protection Level IP20
Housing Material PC

Range

Featuring advanced spatial coverage at a standard mounting height of 3.0 meters, this dual-tech presence sensor offers a micro-motion/stationary detection coverage diameter of approximately 6.0 meters and a major-motion detection coverage diameter of up to 8.0 meters.

Mini-DTP-S2 detection range, Front View
Front View
Mini-DTP-S2 detection range, Side View
Side View

Dimensions

Measuring 43 mm wide and 25 mm deep, this recessed unit fits a 35 mm cutout and requires a minimum ceiling depth of 13 cm.

Product Dimensions
Product Dimensions

Applications

Mini-DTP-S2 application: Home
Home
Mini-DTP-S2 application: Hotel
Hotel
Mini-DTP-S2 application: Lighting
Lighting
Mini-DTP-S2 application: Office
Office
Mini-DTP-S2 application: Security
Security

Mounting

Interference Avoidance: Keep away from moving objects (e.g., curtains, plants) and large metal/reflective surfaces.

Device Spacing: Maintain at least 4m between sensors.

Mounting: Install on a stable, vibration-free surface. Ensure no moving objects are behind the wall (signals penetrate non-metals).

Wiring Safety: Turn off power before wiring. Use certified cables and proper circuit protection.

Disclaimer: Follow wiring diagrams strictly. Manufacturer is not liable for improper installation. Specifications subject to change.

Mini-DTP-S2 wiring diagram
Wiring Diagram

Debugging

IR Remote Control
IR Remote Control

Designed for ultimate convenience and efficiency, this product supports quick on-site configuration and parameter reading using an infrared (IR) remote control. Once deployed, debugging and maintenance can be easily accomplished even without relying on a smart home platform.

FAQ

How is the Mini-DTP-S2 installed?

Installation method: Recessed Ceiling Mount. Mounting height: 2.0 to 3.2 m.

What is the detection coverage of the Mini-DTP-S2?

Detection coverage: Installation at 3.0 m Height:; ① Motion & Micro-motion: Detection diameter at least 8.0 m; ② Stationary Presence: Detection diameter at least 6.0 m. Detection range: 1.5 to 8.0 m (sensor to target). Detection angle: 360°.

How is the Mini-DTP-S2 configured on site?

The Mini-DTP-S2 supports quick on-site configuration and parameter reading with an infrared (IR) remote control, so commissioning and maintenance do not depend on a smart home platform.

What are the operating conditions of the Mini-DTP-S2?

Operating environment: Indoor -20 to 45°C; Humidity < 95% RH (Non-condensing). Protection level: IP20.

Resources

Available Accessories

Remote Controller
Remote Controller P/N: 60.99.00C1

Model: Accessory (RC1)

Mini Accessory Cover Ring
Mini Accessory Cover Ring P/N: 60.99.0A55

Model: A55 (Mini-ASSY-55)

Mini Accessory In-wall Mounting 86 Panel Frame
Mini Accessory In-wall Mounting 86 Panel Frame P/N: 60.99.0A86

Model: A86 (Mini-ASSY-86)

Mini Accessory Borderless Embeded Parts
Mini Accessory Borderless Embeded Parts P/N: 60.99.0A40

Model: A40 (Mini-ASSY-BL)
