24G Radar Presence Sensor (KNX)
No.R5-24G-KNX
SKU: 60.50.2503
Product Model: CTL-SEN-R5/2503
Accurate detection of static and minor motion states
This sensor uses a 24GHz millimeter-wave radar to detect human presence. It adds a life detection algorithm to the existing Creatrol algorithm, offering enhanced anti-interference capabilities and increased detection precision. Its innovative hardware and software design extends its detection range to over 10 meters. It also features a built-in 0-32,000 Lux illuminance meter chip, with independently adjustable sensitivity and detection range.
Installation Height: 2~4m (Ceiling)
Detection Angle: 360°
Detection Range: φ10m (at 3m height)
Illuminance Sensor: 0~32000 Lux
Cut-out Size: φ55mm
KNX Input: KNX 21~30V (6mA)
AUX Input: DC12~30V (0.5W)
Accurate detection of static and minor motion states
This sensor uses a 24GHz millimeter-wave radar to detect human presence. It adds a life detection algorithm to the existing Creatrol algorithm, offering enhanced anti-interference capabilities and increased detection precision. Its innovative hardware and software design extends its detection range to over 10 meters. It also features a built-in 0-32,000 Lux illuminance meter chip, with independently adjustable sensitivity and detection range.
Installation Height: 2~4m (Ceiling)
Detection Angle: 360°
Detection Range: φ10m (at 3m height)
Illuminance Sensor: 0~32000 Lux
Cut-out Size: φ55mm
KNX Input: KNX 21~30V (6mA)
AUX Input: DC12~30V (0.5W)
