| Designation | Value |
| Input Voltage |
AC 100 ~ 240V or DC 24V
|
| Output Voltage |
DC 24V (125mA Max)
|
|
DALI Output Voltage
|
DC 16V (100mA Max)
|
|
Number of Luminaires
|
Recommendation ≤ 25 (Actual capacity depends on the current consumption of luminaire drivers on the DALI bus)
|
|
Product Dimensions
|
84mm * 21mm * 26mm |
|
Box Weight
|
34g
|
|
Wiring Method
|
Terminal blocks (0.5 ~ 2.5mm²), plug-in connector
|
| Operating Temperature |
Indoor -20 ~ 45℃
|
|
Storage Temperature
|
-40 ~ 85℃
|
|
Relative Humidity
|
＜ 95%
|
|
Protection Class
|
IP20
|
|
Shell Material
|
Flame-retardant PC (UL94 V-0) |
